AccuMac AM1660-12 Precision Industrial PRT Probe
Overview
The AM1660 series from AccuMac comprises precision industrial PRTs (IPRTs) built for reference-grade temperature measurement in tough conditions. The AM1660-12 uses a wire-wound sensing element whose supporting structure and filling material are designed to balance hysteresis, mechanical shock and thermal shock performance while protecting the platinum wire from contamination at high temperatures. It follows the standard 385 (DIN/IEC 751) curve and covers -200 to 670 °C.
The probe comes with an ISO/IEC 17025 accredited calibration as standard, so it can be put straight into use as a working reference. A 12-inch Inconel sheath resists harsh environments, and long-term drift is below 0.03 °C at 0 °C after 100 hours at maximum temperature, with short-term stability below 0.01 °C.
Features
- Temperature range -200 to 670 °C
- Accuracy better than 0.035 °C at 0 °C
- Long-term drift below 0.03 °C at 0 °C after 100 hours at maximum temperature
- Short-term stability below 0.01 °C
- Wire-wound platinum sensing element, 385 curve
- Inconel sheath for harsh environments
- Shock-resistant construction
- ISO/IEC 17025 accredited calibration included
Applications
- Reference measurements for calibrating industrial temperature sensors
- Monitoring dry-wells, baths and furnaces in calibration labs
- High-temperature process verification in industrial plants
AccuMac AM1660-12 Precision Industrial PRT Probe Technical Specifications
| Temperature range | -200 °C to 670 °C |
|---|---|
| Nominal resistance at 0 °C | 100 Ohm |
| Temperature coefficient | 0.00385 Ohm/Ohm/°C |
| Accuracy | <0.035 °C at 0 °C |
| Long-term drift | <0.03 °C at 0 °C after 100 hours at maximum temperature |
| Short-term stability | <0.01 °C |
| Thermal shock | <0.007 °C after 10 thermal cycles, min to max temperature |
| Hysteresis | <=0.01 °C |
| Self-heating | 50 mW/°C |
| Response time | 5 seconds |
| Measurement current | 0.5 mA or 1 mA |
| Sensor length / location | 1.26 in (32 mm), 0.2 in (5 mm) from tip |
| Sheath | Inconel, 12 in length, 0.25 in diameter |
| Calibration | ISO/IEC 17025 accredited calibration with data included |
Manufacturer information: AccuMac AM1660/1640/1620 Precision Industrial PRTs
