Ametek Jofra CTC155A Temperature Calibrator
Overview
The CTC-155 A is the basic model, without external reference input, of Jofra's CTC series compact temperature calibrators. Designed for on-site and maintenance-shop calibration, it uses a dedicated temperature regulator for fast heating, cooling and stabilization, and its MVI (mains voltage immunity) circuitry keeps the block stable even when supply power fluctuates.
A large color display shows calibration status, and one-key functions cover Set, Preset, auto stepping and automatic switch testing. The 26 mm well with 120 mm immersion accepts a wide range of aluminum inserts, and the supplied JofraCal software documents RTD, thermocouple, transmitter and switch calibrations. It weighs only 5.5 kg.
Features
- Temperature range -25 to 155 °C (at 23 °C ambient)
- Accuracy ±0.3 °C with internal reference sensor
- Stability ±0.04 °C
- Radial homogeneity 0.03 °C at 155 °C
- Heats 23 to 155 °C in 13 min; cools 155 to 23 °C in 12 min
- MVI mains voltage immunity
- Color display with auto step, preset and switch test modes
- USB 2.0 with JofraCal calibration software
Applications
- On-site and workshop calibration of process sensors and switches
- Calibration of liquid-filled sensors and thermostats
- Three-point temperature calibration procedures
What's in the Box
- CTC-155 dry-block calibrator
- Mains power cable
- Traceable temperature performance certificate
- Tool for insertion tubes
- User manual
- Test cables (1 red, 1 black)
- USB cable
- JofraCal calibration software
Ametek Jofra CTC155A Temperature Calibrator Technical Specifications
| Temperature range | -25 to 155 °C (-13 to 311 °F) at 23 °C ambient |
|---|---|
| Accuracy, internal reference | ±0.3 °C (±0.54 °F) |
| Stability | ±0.04 °C (±0.07 °F) |
| Radial homogeneity | 0.03 °C at 155 °C; 0.02 °C at -25 °C |
| Heating / cooling time | 13 min (23 to 155 °C); 12 min (155 to 23 °C) |
| Time to stability | 10 min typical |
| Resolution / units | 1, 0.1 or 0.01; °C, °F or K |
| Well diameter / immersion depth | 26 mm / 120 mm |
| Dimensions (L × W × H) | 248 × 148 × 305 mm; 5.5 kg |
| Mains power | 115 V (90-127) or 230 V (180-254); 130 VA |
| Digital interface | USB 2.0; switch test max 14 VDC, 1 mA |
| Environment / safety | 0 to 50 °C operating, 5-90% RH; IP-10 |
